STEEL AIDS (INDIA)is the leading engineering firm well-known for its high quality and superior products. The company is mainly working as a prominent supplier and manufacturer that offers high-quality Stainless-steel wire. For the production of high-grade Stainless-Steel Wire,we procure superior quality raw material from an authentic supplier. We ensure to design and develop products that have soldering and welding abilities. Stainless steel wire is a mechanical product available in different shapes, sizes, and specifications to match customer requirements. Along with this, we understand the operational conditions of the client company. We at STEEL AIDS (INDIA), our expert designs and develops products to obtain customer satisfaction. Stainless steel wire is the product available in varied sizes and shapes to match customer needs.
Stainless Steel Wire Mesh, SS Lashing Wire, SS Welding Wire Exporter, SS Bright Wire, Stainless Steel Spring Wires, Stainless Steel Filler Wire, Stainless Steel Cold Heading Wires, Stainless Steel Tig Wires, Stainless Steel Wire Bobbin Dealer, Stainless Steel Wires Stockist in India.
Duplex Steel Wire
Duplex Stainless Steel S31803 Welding Wire Exporter, Duplex Steel S31803 Wire Mesh, Duplex Steel S31803 Lashing Wire, S31803 Duplex Steel Wire Bobbin Dealer, S31803 Duplex Steel Filler Wire, Duplex Stainless Steel S31803 Bright Wire, S31803 Duplex Steel Tig Wires, Duplex Steel 1.4462 Cold Heading Wires, S31803 Spring Wires, Duplex S31803 Wires Stockist in India.
Duplex Steel S31803 Wire Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
Duplex Steel S31803 Wires Mechanical Properties
| Grade | Density | Melting Point | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min |
|---|---|---|---|---|---|
| S31803 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 116000 , MPa – 800 | Psi – 80000 , MPa – 550 | 15 % |
High Nickel Alloy
Inconel 600 Wire Mesh, Inconel N06600 Lashing Wire, Inconel® Alloy 600 Welding Wire Exporter, Inconel 600 Bright Wire, Alloy 600 Spring Wires, 600 Inconel Filler Wire, Inconel 2.4816 Cold Heading Wires, 600 Inconel Tig Wires, 600 Inconel Wire Bobbin Dealer, Inconel Alloy 600 Wires Stockist in India.
Inconel 600 Wire Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
Inconel 600 Wires Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
Titanium Wire
Titanium Alloy Gr 2 Welding Wire Exporter, Titanium Gr 2 Wire Mesh, Titanium R50400 Lashing Wire, Gr 2 Titanium Wire Bobbin Dealer, Gr 2 Titanium Filler Wire, Ti. Gr 2 Bright Wire, Gr 2 Titanium Tig Wires, Titanium 3.7035 Cold Heading Wires, Ti. Alloy Gr 2 Spring Wires, Titanium Alloy Grade 2 Wires Stockist in India.
Titanium Grade 2 Wire Chemical Composition
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade 2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | - | - |
Titanium Grade 2 Wires Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Ti Gr.2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
Alloy 20 Wire
Alloy N08020 Lashing Wire, Incoloy® alloy 20 Spring Wires, Alloy 20 Welding Wire Exporter, Alloy 2.4660 Cold Heading Wires, Alloy 20 Bright Wire, Alloy 20 Tig Wires, Carpenter 20 Wire Mesh, Alloy 20 Wire Bobbin Dealer, Alloy 20 Filler Wire, Carpenter 20 Wires Stockist in India.
Alloy 20 Wire Chemical Composition
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
Alloy 20 Wires Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi - 35,000, MPa - 241 | 30 % |
